Lightweight Meilenstein Evo / Schwarz Ed Wheelset

LIGHTWEIGHT MEILENSTEIN EVO DISC / SCHWARZ ED

LIGHTWEIGHT wheelset 28 "milestone EVO Disc | Clincher | SCHWARZ ED

The new Lightweight Meilenstein EVO is here, either you drive it or you overtake it! Since their market launch, the full carbon wheels from Friedrichshafen have been among the most sought-after wheel sets for racing bike enthusiasts as well as professional riders. For Lightweight, however, this is no reason to rest on your laurels, but motivation to significantly improve each new generation of wheelsets and to equip them with new features.

The EVO milestone is one of the lightest high-profile disc wheelsets on the market. Thanks to the use of special CFRP fibers in combination with a new layer structure, it is even more stable and durable. For the driver, this means even more efficient power transmission, excellent handling and, above all, even more speed. Despite the enormous rigidity, the comfort factor could also be increased in order to conserve the driver's strength on long journeys. Also new are the highly modular full carbon spokes specially developed for disc brakes. These help to transfer the braking forces better and ensure extremely precise braking behavior. The rim width increased to 18.2 millimeters and the tubeless-ready profile provides a further intended use . In addition to the use of road tubeless tires, the EVO Disc milestone has also been approved for the use of cyclocross and gravel bikes.

The interior of the DT Swiss 240s hubs ensures smooth running and long durability, which is hidden under the innovative Pentagon hub shell made of carbon. In addition to its special appearance, the design prevents the hub body from overheating on long pass runs. With the built-in CeramicSpeed bearings, the SCHWARZ ED also helps you hunt for seconds.

Various adapter sets enable the wheel set to be optimally adapted to all axle type standards.

Adapter set 1 standard
End cap front 12x100 mm thru axle
End cap HR 12x142 mm thru axle

Adapter set 2 thru axle
End cap front 15x100 mm thru axle
End cap HR 12x135 mm thru axle

Adapter set 3 thru bolt
End cap VR 9x100 mm Thru Bolt (incl. 9 mm RWS quick release)
End cap HR 10x135 mm Thru Bolt (incl. 10 mm RWS quick release)

Adapter set 4 complete
End cap VR 9x100 mm Thru Bolt (incl. 9 mm RWS quick release)
End cap front 12x100 mm thru axle
End cap front 15x100 mm thru axle
End cap HR 10x135 mm Thru Bolt (incl. 10 mm RWS quick release)
End cap HR 12x135 mm thru axle
End cap HR 12x142 mm thru axle

Lightweight ensures crash replacement for all wheels!

Technical specifications:

intended use : road bike, cyclocross, gravel
Wheel size: 28 "(ETRTO: 622 x 18.2 mm)
Rim type: clincher (clincher and folding tire)
Brake type: for disc brake only
Brake disc mount: Centerlock (6-hole adapter included)
Material: carbon, aluminum, stainless steel
Inner width: 18.2 mm
Outside width: 24 mm
Rim height: 48 mm
Number of holes: -
Front axle type standard: 12x100 mm thru axle, 9x100 mm Thru Bolt or 15x100 mm thru axle
axle type back: 12x142 mm thru-axle, 10x135 mm thru bolt or 12x135 mm thru axle
Front bearing : 2x Ceramic Speed ball bearings (Ceramic Hybrid)
Rear bearing : 4x Ceramic Speed ball bearings (Ceramic Hybrid)
Seal: labyrinth rubber seals
Freewheel compatibility: 10-, 11-speed Shimano Road; 12-speed SRAM XDR or 10-, 11-, 12-speed Campagnolo
Freewheel type: 2 tooth lock washers, 18 grids
Spokes: Carbon 20 front / 20 rear
tubeless capable: yes
recommended tire width: 23-32 mm
maximum system weight: 120 kg (driver incl. bike, clothing and luggage)
Finish: 3K carbon glossy
Color: carbon with lasered logos and black lightweight lettering

Weight according to the manufacturer: 1380g (650g VR, 730g HR )
Weight weighed: 1399g
